混凝土攪拌機有各種各樣的參數，每個參數都代表了各自不同的意義，很多時候我們選擇混凝土攪拌機的時候參數都是重要的參考對象。以下小編為您收集整理的混凝土攪拌機參數的詳解。

Concrete mixers have a variety of parameters, each of which represents its own different meaning. Many times, when we choose concrete mixers, parameters are important reference objects. The following is a detailed explanation of the concrete mixer parameters you have collected.

(1)額定容量

(1) Rated capacity

額定容量分為進料容量和出料容量。我國規定的泄流能力是表示力學模型的主要參數。給料能力(也稱為裝載量)是指裝入攪拌筒的物料的單位體積，用l表示；卸料能力是指卸出的物料(混凝土等)。).體積單位用m表示。

The rated capacity is divided into feed capacity and discharge capacity. The discharge capacity specified in China is the main parameter of the mechanical model. Feeding capacity (also known as loading capacity) refers to the unit volume of materials loaded into the mixing drum, expressed in L; Unloading capacity refers to the discharged materials (concrete, etc.) The unit of volume is expressed in M.

(2)工作時間

(2) Working hours

攪拌機的工作時間可分為：裝料時間，即從加料開始到攪拌筒，到裝料過程結束；出料時間，從出料到出料少95%的攪拌物料；攪拌時間，從加料結束到出料開始；周期時間是指在連續生產條件下，從上一個投料工序開始到下一個投料工序開始的時間，即一個操作周期的總時間。

The working time of the mixer can be divided into: charging time, that is, from the beginning of charging to the mixing drum to the end of the charging process; Discharging time: at least 95% of the mixed materials from discharging to discharging; Mixing time, from the end of feeding to the beginning of discharging; Cycle time refers to the time from the start of the previous feeding operation to the start of the next feeding operation under continuous production conditions, that is, the total time of an operation cycle.

(3)攪拌速度

(3) Mixing speed

攪拌速度一般用n表示，單位為r/min拌筒旋轉自落式混合機的n值一般為14---33r/min，常用的n值約為18r/min。帶葉片的強制攪拌機的n值一般為20-38r/min，常用的n值為36-38r/min。

The mixing speed is generally expressed in N, and the unit is R / min. The n value of the drum rotating self falling mixer is generally 14-33 R / min, and the commonly used n value is about 18 R / min. The n value of forced mixer with blades is generally 20-38 R / min, and the commonly used n value is 36-38 R / min.

2.混凝土攪拌機生產率計算

2. Productivity calculation of concrete mixer

攪拌機的生產率取決于攪拌一罐混凝土所需的時間和每個罐的排出量。

The productivity of the mixer depends on the time required to mix one tank of concrete and the discharge volume of each tank.

3、混凝土攪拌機根據工程類型的選擇

3. Selection of concrete mixer according to project type

(1)從工程量和工期方面

(1) In terms of quantities and construction period

當混凝土量大、工期長時，應選擇中型或大型固定式混凝土攪拌機作為攪拌站。當混凝土量少、工期短時，應選用中小型移動式攪拌機。

When the concrete volume is large and the construction period is long, the medium-sized or large-sized fixed concrete mixer shall be selected as the mixing station. When the amount of concrete is small and the construction period is short, small and medium-sized mobile mixers shall be selected.

(2)從混凝土性能的設計

(2) From the design of concrete performance

當混凝土為塑性或半塑性時，應選用自落式攪拌機；當混凝土強度高、干燥或輕質時，應選用強制攪拌機。

When the concrete is plastic or semi plastic, the self falling mixer shall be selected; When the concrete is strong, dry or light, a forced mixer shall be selected.

(3)考慮混凝土的組成特點和稠度

(3) Considering the composition characteristics and consistency of concrete

當密度較小時，骨料粒徑較大時，應選用大容量的自落式攪拌機；當稠度較大，骨料粒徑較大時，應選擇攪拌筒速度較快的自落式攪拌機；如果稠度較大，骨料粒徑較小，應選擇中、小容量的強制式攪拌機或錐形反卸式攪拌機。

When the density is small and the aggregate size is large, a large capacity self falling mixer shall be selected; When the consistency is large and the aggregate particle size is large, the self falling mixer with high mixing drum speed shall be selected; If the consistency is large and the aggregate particle size is small, the medium and small capacity forced mixer or conical reverse dump mixer shall be selected.

混凝土攪拌機主要的參數詳解講解完畢了，希望能夠給您使用中的幫助，當然您在選購該攪拌機的時候也可以作為參考信息使用，更多內容來我們網站http://www.wishnailspa.com咨詢！

The main parameters of the concrete mixer have been explained in detail. I hope I can help you in using it. Of course, you can also use it as reference information when purchasing the mixer. For more information, please visit our website http://www.wishnailspa.com consulting service
