The shaft mixer is a device for spraying, humidifying and stirring conveying powdery materials by using a pair of helix axes with stirring blades. It can be used to stir and crush clay materials in ceramic industry; Fly ash, aggregate, admixture and other raw materials shall be evenly mixed. The equipment has the advantages of high mixing efficiency, compact structure, stable operation, cleanness and environmental protection. It is used in chemical, mining, ceramsite and other industries to humidify, stir and transport solid granular materials or powder materials.

雙軸混合機的突出優點如下:

The outstanding advantages of double shaft mixer are as follows:

1、整個攪拌、輸送過程在密封空間內進行，無粉塵泄漏，清潔;

1. The whole mixing and conveying process is carried out in a sealed space, without dust leakage, clean and environmental protection;

2、是混合、加濕、輸送相結合，均勻性好，生產效率高，產能大;

2. It is a combination of mixing, humidification and transportation, with good uniformity, high production efficiency and large production capacity;

3、軸端采用迷宮式和填料式組合密封，起到雙重密封作用，密封效果好;

3. The shaft end adopts labyrinth and packing combined seal, which plays a double sealing role and has good sealing effect;

4、攪拌葉片采用耐磨材料制成，經過特殊表面處理后具有較高的耐磨性;

4. The mixing blade is made of wear-resistant material, which has high wear resistance after special surface treatment;

5、整機結構緊湊，空間小，傳動平穩，可靠性高，噪音低。

5. The whole machine has the advantages of compact structure, small space, stable transmission, high reliability and low noise.

雙軸混合器的主要結構如下圖所示，主要包括驅動裝置、進料口螺桿葉片軸、罐體、出料口等部件。驅動裝置由電機聯軸器、減速機、齒輪副組成。電機通過聯軸器帶動減速機，再帶動齒輪副運行，實現兩個斜葉片軸的相移。螺旋葉片安裝在螺旋葉片軸上，螺旋葉片由耐磨材料制成。物料通過進料口進入罐內，由螺旋葉片攪拌破碎。物料粒度均勻后從出料口出料。

The main structure of the double shaft mixer is shown in the figure below, mainly including driving device, feed port screw blade shaft, tank body, discharge port and other components. The driving device is composed of motor coupling, reducer and gear pair. The motor drives the reducer through the coupling, and then drives the gear pair to realize the phase shift of the two inclined blade shafts. The spiral blade is installed on the spiral blade shaft, and the spiral blade is made of wear-resistant material. The materials enter the tank through the feed inlet and are stirred and broken by spiral blades. After the particle size of the material is uniform, the material is discharged from the discharge port.
