1. Explanation on oil leakage of reducer of concrete mixer

(1)在封閉的減速機箱內，每一對齒輪相嚙合及齒輪浸入油中攪油都發生熱量。跟著運轉時間的持久，使減速箱內溫度逐增加，箱體內潤滑油經飛濺，灑在減速機箱體內壁，因潤滑油的粘度隨溫度升高而低落，油的滲透性更強，在箱內壓力浸箱面或軸伸密封不嚴處滲漏。

(1) In the closed reduction case, heat is generated when each pair of gears mesh and the gears are immersed in oil. With the lasting operation time, the temperature in the reduction box increases gradually. The lubricating oil in the box is splashed and sprinkled on the inner wall of the reduction box. Because the viscosity of the lubricating oil decreases with the increase of temperature, the oil permeability is stronger, and it leaks at the pressure immersed box surface in the box or the shaft extension seal is not tight.

(2減速機結構不公道引起漏油。如設計的減速機沒有通風罩或通風罩太小，減速機無法實現均壓，也會造成箱內壓力升高

(2) the unreasonable structure of the reducer causes oil leakage. If the designed reducer does not have a ventilation hood or the ventilation hood is too small, the reducer cannot achieve pressure equalization, and the pressure in the box will also rise

(3)減速機事情情況惡劣引起漏油。如情況多塵造成通風罩通風結果差，不能實現均壓，高溫及有害介質，使密封件老

(3) The reducer is in bad condition, causing oil leakage. If the ventilation result of the ventilation hood is poor due to too much dust, pressure equalization cannot be realized, high temperature and harmful media will make the seal old

(4)裝配質量達不到要求，在維修安裝減速機封蓋時團結面密封欠好，也會呈現漏油現象。

(4) If the assembly quality fails to meet the requirements, the sealing of the unity surface is not good when repairing and installing the reducer cover, which will also show oil leakage.

2、防備混凝土攪拌車減速機漏油的法子

2. Ways to prevent oil leakage of reducer of concrete mixer truck

(1)均壓。減速機漏油主要是由于減速機箱內壓力增加所引起，因此減速機應設有相應的通風罩，以實現箱內和箱外壓力

(1) Equalizing. The oil leakage of the reducer is mainly caused by the increase of pressure in the reducer box. Therefore, the reducer shall be equipped with corresponding ventilation hood to realize the pressure inside and outside the box

速機較量大，通風罩不能太小。通風罩巨細的輕便查抄要領是：打開通風罩上蓋，減速機以高速持續運轉幾分鐘之后，用壓差較大時，說明通罩小，則應改換通風罩，確保均壓。對在惡劣情況事情的減速機應經常查抄通風罩的通風結果，發明

There is a big competition between speed machines, and the ventilation hood should not be too small. The key points of light inspection of the size of the ventilation hood are: open the upper cover of the ventilation hood, and after the reducer runs continuously at high speed for several minutes, if the pressure difference is large, it indicates that the ventilation hood is small, then the ventilation hood should be replaced to ensure pressure equalization. Check the ventilation results of the ventilation hood frequently for the reducer in bad conditions

(2)導流。減速機在高速運轉時，由于齒輪浸在油池中，在旋轉時將油帶起飛濺到箱體內壁，要使飛濺到箱體內壁的油盡及軸頭密封處存留，以防油逐漸沿上下箱體之間及軸頭浸出來?？稍跍p速機上下箱體團結面處開回油槽，在軸頭設計出油軸頭處粘一半圓槽，使濺到上蓋的油順半圓槽兩頭流到下箱中，使飛濺到箱體上的油不會漏出。

(2) Diversion. When the reducer is running at high speed, because the gear is immersed in the oil pool, the oil belt will take off and splash on the inner wall of the box during rotation. The oil splashed on the inner wall of the box and the seal of the shaft head shall be retained to prevent the oil from gradually soaking out between the upper and lower boxes and the shaft head. The oil return groove can be opened at the joint surface of the upper and lower boxes of the reducer, and the oil is designed at the shaft head. The half round groove is stuck at the shaft head to make the oil splashed on the upper cover flow into the lower box along the two ends of the half round groove, so that the oil splashed on the box will not leak out.
